Lopolight 5nm 225deg Masthead White

Product Description

Lopolight 300-036 - Navigation Light 5NM 225° White, Masthead, Silver Anodized

This horizontally mounted navigation light includes a HDPE base plate and two cable gland sizes to fit cable diameters from 7 to 13 mm (9/32" - 1/2"). It is designed for vessels between 20 and 50 meters and offers reliable 5 nautical mile visibility with a white light beam spanning 225°.

• Article number: 186836
• Light color: White
• Dimensions: Ø92.5mm x 111.8mm (Ø3.6" x 4.4")
• Certification: Certified by DNV
• Intensity: >52 cd
• Approved to: COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR
• Visibility range: 5 nautical miles
• Operating temperature: -25°C to 55°C
• Mounting: Horizontal on 400-034 aluminum base (IP68)
• Cable direction options: Side or down
• Included: HDPE base plate, quality cable glands (7-13 mm diameter)
• Materials: Silver anodized aluminum 25µ, PMMA lens, A4 stainless steel screws, epoxy, polyurethane
• Operating voltage: 20-32 VDC
• Power draw: 7 W
• Current consumption: 0 mA @ 12VDC, 290 mA @ 24VDC
• Vessel size suitability: 20-50 meters
• Minimum feed wire gauge: 0.5mm² (AWG22)
• Weight: 1.35 kg (47.61 oz)
• Connection: Plug connector
• EAN: 5704438001657
• UPC Code: 879343001650

Lopolight 300-036-B-CD - Navigation Light 5nm 225° White, Masthead, Black Anodized

This high-quality navigation light is designed for vessels between 20 and 50 meters. It provides reliable white illumination with excellent visibility and robust construction for harsh marine environments.

• Mounting: Horizontally mounted on 400-035 aluminum base (IP68), cable direction down
• Included Accessories: HDPE base plate, high-quality cable glands
• Cable Gland Size: 7-13mm (9/32"-1/2") cable diameter
• Light Color: White
• Light Number: 300-036-B-CD
• Intensity: >52cd
• Visibility: 5 nautical miles
• Operating Temperature: -25°C to 55°C
• Mounting Orientation: Horizontal
• Materials: Black anodized aluminum 25µ, PMMA lens, A4 stainless steel screws, epoxy, polyurethane
• Operating Voltage: 20-32VDC
• Power Draw: 7 W
• Current Consumption: 0 mA @ 12VDC, 290 mA @ 24VDC
• Connection: Plug connector
• Minimum Feed Wire Gauge: 0.5mm² (AWG22)
• Vessel Size: 20-50 meters
• Weight: 1.02 Kg (35.98 Oz)
• Dimensions (Metric): Ø92.5mm x 111.8mm
• Dimensions (Imperial): Ø3.6" x 4.4"
• Certifications: DNV certified
• Approved to: COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR
• IP Rating: IP68
• EAN: 5704438013384
• UPC Code: 879343013387

Lopolight 300-036-B-CD - Navigation Light 5nm 225° White, Masthead, Black Anodized

This high-quality navigation light is designed for vessels between 20 and 50 meters. It provides reliable white illumination with excellent visibility and robust construction for harsh marine environments.

• Mounting: Horizontally mounted on 400-035 aluminum base (IP68), cable direction down
• Included Accessories: HDPE base plate, high-quality cable glands
• Cable Gland Size: 7-13mm (9/32"-1/2") cable diameter
• Light Color: White
• Light Number: 300-036-B-CD
• Intensity: >52cd
• Visibility: 5 nautical miles
• Operating Temperature: -25°C to 55°C
• Mounting Orientation: Horizontal
• Materials: Black anodized aluminum 25µ, PMMA lens, A4 stainless steel screws, epoxy, polyurethane
• Operating Voltage: 20-32VDC
• Power Draw: 7 W
• Current Consumption: 0 mA @ 12VDC, 290 mA @ 24VDC
• Connection: Plug connector
• Minimum Feed Wire Gauge: 0.5mm² (AWG22)
• Vessel Size: 20-50 meters
• Weight: 1.02 Kg (35.98 Oz)
• Dimensions (Metric): Ø92.5mm x 111.8mm
• Dimensions (Imperial): Ø3.6" x 4.4"
• Certifications: DNV certified
• Approved to: COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR
• IP Rating: IP68
• EAN: 5704438013384
• UPC Code: 879343013387

5nm 225° White, Masthead, silver anodized

• P/N: 300-036-CD
• 5 nm Masthead, silver anodized
• Horizontally mounted on 400-035 alu base (IP68)
• Cable direction down
• incl. HDPE base plate
• Quality cable glands - 1 sizes included:
• 7-13mm (9/32"- 1/2") cable diameter

Lopolight 300-036-PRO - Navigation Light 5NM 225° White, Masthead, Black Anodized

Engineered for medium-sized vessels, this navigation light features a horizontal POM base, side-facing cable orientation, and durable hard coat anodized aluminum for long-lasting performance.

• Mounting: Horizontally on POM base (IP68), cable direction side
• Included Accessories: HDPE base plate, quality cable glands
• Cable Gland Size: 7-13mm (9/32"-1/2")
• Light Color: White
• Number: 300-036-PRO
• Intensity: >52cd
• Visibility: 5 nautical miles
• Operating Temperature: -25°C to 55°C
• Materials: Black hard coat anodized aluminum 50µ, PMMA lens, A4 stainless steel screws, epoxy, polyurethane
• Operating Voltage: 20-32VDC
• Power Draw: 7 W
• Current Consumption: 0 mA @ 12VDC, 290 mA @ 24VDC
• Connection: Plug connector
• Minimum Feed Wire Gauge: 0.5mm² (AWG22)
• Vessel Size: 20-50 meters
• Weight: 1.31 Kg (46.20 Oz)
• Dimensions (Metric): Ø92.5mm x 111.8mm
• Dimensions (Imperial): Ø3.6" x 4.4"
• Certifications: DNV certified
• Approved to: COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR
• IP Rating: IP68
• EAN: 5704438005716
• UPC Code: 879343005719

Lopolight 300-036-PRO-I - Navigation Light 5NM 225° White, Masthead, Ice-Class, Black Anodized

This ice-class navigation light includes a built-in de-icing function, ideal for vessels operating in extreme cold. It is mounted horizontally on a POM base with side-facing cable orientation.

• Mounting: Horizontally on 400-037 POM base (IP68), cable direction side
• Included Accessories: HDPE base plate, quality cable glands
• Cable Gland Size: 7-13mm (9/32"-1/2")
• Light Color: White
• Number: 300-036-PRO-I
• Intensity: >52cd
• Visibility: 5 nautical miles
• Operating Temperature: -60°C to 55°C
• Materials: Black hard coat anodized aluminum 50µ, PMMA lens, A4 stainless steel screws, epoxy, polyurethane
• Operating Voltage: 20-32VDC
• Power Draw: 7 W
• Current Consumption: 0 mA @ 12VDC, 290 mA @ 24VDC
• Connection: Plug connector
• Minimum Feed Wire Gauge: 1.5mm² (AWG18)
• Vessel Size: 20-50 meters
• Weight: 1.34 Kg (47.26 Oz)
• Dimensions (Metric): Ø92.5mm x 111.8mm
• Dimensions (Imperial): Ø3.6" x 4.4"
• Certifications: DNV certified
• Approved to: COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR
• IP Rating: IP68
• EAN: 5704438011304
• UPC Code: 879343011307
