Shadow-Caster SCM SL Spreader Light Mount Black Housing

Product Description

The SHADOW-CASTER® marine LED Spreader Light SCM-SL is perfect for illuminating decks and other large areas of your boat or yacht.  It has a unique reflector design which spreads the light beams out to reduce glare.

The marine LED Spreader Light comes in black or white ?nish. It is available in 3 color output options: single color white; 3 color (white , blue and red ) as well as a full color version. The brightness and color can be controlled with a standard switch or use a Shadow-NET® enabled controller to enjoy unlimited colors with the full color model.

The flush mount version is great for mounting in T-Tops or use the bracket mount version to retro?t existing installations.

KEY FEATURES

• Soft start technology ramps the brightness up gently over 2 seconds
• Power toggle feature to set brightness and change color
• True white LED for best color performance
• Unique reflector design to reduce glare
• High ef?ciency switch mode power supply
• Waterproof low-pro?le aluminum housing
• White or black ?nish
• 3-Year Warranty

COLORS AVAILABLE / PART NUMBER

Full Color – 12 color lights
SCM-SLF-CC-WH(flush mount, white housing)
SCM-SLF-CC-BK (flush mount, black housing)
SCM-SLB-CC-WH (bracket mount, white housing)
SCM-SLB-CC-BK (bracket mount, black housing)

White, Blue & Red – 3 color lights
SCM-SLF-WBR-WH (flush mount, white housing)
SCM-SLF-WBR-BK (flush mount, black housing)
SCM-SLB-WBR-WH (bracket mount, white housing)
SCM-SLB-WBR-BK (bracket mount, black housing)

Great White – 1 color light
SCM-SLF-GW-WH (flush mount, white housing)
SCM-SLF-GW-BK (flush mount, black housing)
SCM-SLB-GW-WH (bracket mount, white housing)
SCM-SLB-GW-BK (bracket mount, black housing)

SPECIFICATIONS

• 2200 lumen output
• 60° beam angle
• 24 watt power draw
• 10-30 volts input
• 2A at 12 volts, 1A at 24 volts
• 6200 Kelvin cool white color temperature
• Durable glass lens
• IP67 waterproof design
• Full color version includes Shadow-NET® interface for controlling color
• SCM-SLB Series: 4.25″ (108mm) overall width x 1.6″ (41mm) height x 2.8″ (71mm) mounting depth
• SCM-SLF Series: 5″ (127mm) overall width x 1.7″ (43mm) height x 1.6″ (41mm) mounting depth

CONTROL OPTIONS

POWER TOGGLE CONTROL
Quickly toggle power source to advance to next color or brightness level.

SHADOW-NET® CONTROL
Full-feature control through your Multifunction Display (MFD) by adding the Shadow-NET® Light Commander control module (SCM-LC-N2K-PLUS-V2) & app.

Dramatically enhanced lighting capabilities through your existing MFD allows for unlimited shades of color and fading, dimming, strobe rate, music sync, multiple zones and much more.
