Product Description

What is the TBB-M12100?

The TBB-M12100 is a high-performance 105Ah 12V Lithium Iron Phosphate (LiFePO4) battery, designed by TBB Mobile for superior safety, efficiency, and longevity. Featuring a built-in 200A BMS, low-temperature heating function, and parallel expandability, it is an ideal solution for energy storage in vehicles, marine applications, and off-grid power systems.

With an intelligent battery management system (BMS), the TBB-M12100 actively monitors and protects against common battery risks, ensuring stable and reliable operation.

Key Benefits of the TBB-M12100


Long Cycle Life: Provides up to 3,000 cycles at 25°C, 0.5C charge/discharge rate, far exceeding traditional lead-acid batteries.
High-Performance BMS: Offers full protection against:

Overcharging & over-discharging
Over-current & short circuits
High & low-temperature operation
Cell voltage balancing & cycle life tracking


High Discharge Capacity: Supports a maximum 200A discharge current for high-power applications.
Parallel Expandability: Supports up to 8 units in parallel, increasing total capacity to 12V 840Ah.
Automatic Wake-Up: In shutdown mode, if an external charging voltage >14V is detected, the battery will automatically activate, enabling charging while preventing discharge.
Optional MEH-B Display Panel: By connecting the optional TBB-MCK remote meter to the battery, this enables extra monitoring and control features such as battery switch control and real-time monitoring of voltage, current, and State of Charge (SOC).
Low Power Consumption:

<50mA standby consumption when powered on
<0.1mA ultra-low standby draw when powered off


Wide Operating Temperature: Functions from -30°C to +60°C, with excellent cycle life and discharge performance even at high temperatures.
Integrated Low-Temperature Heating: When connected to an external power source (mains, solar, or vehicle engine), the built-in heating function automatically raises the battery temperature to allow safe charging and discharging. Heating from -20°C to +5°C takes approximately 30 minutes.
Compact & Lightweight: Smaller and lighter than lead-acid alternatives, offering high energy density and space efficiency.




Advanced Protection Features

The TBB-M12100 incorporates multiple layers of safety protection, including:


Short Circuit Protection
Over-Current Protection
Battery Low Voltage & High Voltage Protection
Cell Low Voltage & High Voltage Protection
Discharge & Charging Temperature Protection
BMS Circuit Over-Temperature Protection
External Input Overvoltage Protection




The TBB-M12100 is an advanced energy solution for those seeking durability, safety, and efficiency in a compact lithium battery system. Whether for off-grid power, vehicle energy storage, or marine applications, it delivers outstanding performance and reliability.



For more details and technical specifications, click on the Details and Specifications tab.
