Lopolight 6nm 225deg White Masthead

Product Description

Lopolight 300-136 - Navigation Light 6NM 225° White, Masthead, Horizontal Mount, Anodized

This navigation light is designed for vessels over 50 meters, featuring a durable silver anodized aluminum body and a high-intensity white light visible up to 6 nautical miles. It is built to withstand harsh marine environments and meets multiple international certifications.

• Item number: 186936
• Supplier article code: 300-136
• EAN code: 5704438007598
• Light color: White
• Dimensions (metric): Ø92.5mm x 111.8mm
• Dimensions (imperial): Ø3.6" x 4.4"
• Certification: DNV certified
• Approved to: COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR
• Visibility range: 6 nautical miles
• Intensity: >94cd
• Operating temperature: -25°C to 55°C
• Mounting orientation: Horizontal
• Materials: Silver anodized aluminum 25µ, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane
• Operating voltage: 20-32 VDC
• Power draw: 13 W
• Current consumption at 12 VDC: 0 mA
• Current consumption at 24 VDC: 580 mA
• Minimum feed wire gauge: 0.5mm² AWG22
• Weight: 1.32 Kg (46.56 Oz)
• IP rating: IP68
• Connection type: Plug connector
• Packaging unit: Piece

Lopolight 300-136-B-RPM - Navigation Light 6NM 225° White Masthead Single Dimmable Black

Experience reliable and high-performance navigation with the Lopolight 300-136-B-RPM. Designed for vessels over 50 meters, this light combines precise visibility, robust materials, and versatile dimming features.

• Dimmable, monitored, and controllable
• Power and control via 2-lead connection
• Light Number: 300-136-B-RPM
• Light Color: White
• Dimensions (metric): Ø92,5mm x 126,8mm
• Dimensions (imperial): Ø3.6" x 4.9"
• Certified by DNV
• Intensity: >94cd
• Approved to COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR
• Visibility: 6nm
• Operating temperature: -25°C to 55°C
• Mounting: Horizontal
• Materials: Black anodized aluminum 25µ, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane
• Operating Voltage: 20-32VDC
• Power Draw: 13 W
• Current consumption: 0 mA @ 12VDC, 580 mA @ 24VDC
• Connection: Plug connector
• Special Attributes: Dimmable (NAVY/SAR only)
• Minimum feed wire gauge: 0.5mm² (AWG22)
• Weight: 1.32 Kg / 46.56 Oz
• EAN: 5704438015227
• UPC Code: 879343015220
• IP Rating: IP68

Lopolight 300-136-B-RPM-I - Navigation Light 6NM 225° White Masthead Dimmable Black Ice-Class

The Lopolight 300-136-B-RPM-I offers the same reliable navigation as the standard model with the added advantage of an ice-class defroster, perfect for cold environments and ice-prone waters.

• Dimmable, monitored, and controllable
• Includes built-in ice-class defroster
• Power and control via 2-lead connection
• Light Number: 300-136-B-RPM-I
• Special Attributes: Ice-class defroster included, Dimmable (NAVY/SAR only)
• Weight: 1 Kg / 35.27 Oz
• EAN: 5704438041523
• UPC Code: 879343041656

Lopolight 300-136-PRO - Navigation Light 6NM 225° White Masthead Black Anodized

This 6NM navigation light is horizontally mounted on a 400-037 POM base and offers high durability for vessels over 50 meters. It comes with quality cable glands and a protective HDPE base plate.

• Article number: 300-136-PRO
• Light Color: White
• Visibility: 6NM
• Intensity: >94cd
• Operating Voltage: 20-32VDC
• Current consumption: 0 mA @ 12VDC, 580 mA @ 24VDC
• Power draw: 13 W
• Dimensions (metric): Ø92.5mm x 126.8mm
• Dimensions (imperial): Ø3.6" x 4.9"
• Mounting: Horizontal
• Materials: Black hard coat anodized aluminum 50µ, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane
• Min. feed wire gauge: 0.5mm² AWG22
• Cable compatibility: 7-13mm (9/32"–1/2") diameter
• Connection: Plug connector
• Approved to: COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR
• Operating temperature: -25°C to 55°C
• IP rating: IP68
• Vessel size: Over 50M
• EAN: 5704438004795
• UPC: 879343004798

Lopolight 300-136-PRO-EX - Navigation Light 6NM 225° White Masthead Single Black Ex Zone 1&2

Reliable and certified navigation light designed for ATEX Zone 1 & 2 environments, ideal for large vessels over 50 meters. Provides excellent visibility while ensuring safe operation in hazardous areas.

• Certified for ATEX Zone 1 & 2 use
• Mounted horizontally on 400-037-B aluminum base (IP68)
• Cable direction: side, includes HDPE base plate
• No cable glands or ground strap included
• Model Number: 300-136-PRO-EX
• Light Color: White
• Dimensions: Ø92.5mm x 140.8mm (3.6"" x 5.5"")
• Certifications: DNV, Dancert (Ex mb eb IIB T5 Gb), ExVeritas (PQAN/UKQAN/QAR)
• Light Intensity: >94cd
• Approved to: COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, BV, RINA, LR, MCA, ATEX 2014/34/EU, IEC 60079-0/7/18, UK Ex
• Visibility Range: 6 NM
• Package Includes: 1 Navigation light, Installation guide
• Operating Temperature: -25°C to 55°C
• Mounting: Horizontal
• Materials: Black hard coat anodized aluminum 50µ, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane
• Operating Voltage: 20-32VDC
• EAN: 5704438040533
• IP Rating: IP68
• Power Draw: 3 W
• Connection: Plug connector
• Current Consumption: 0 mA @ 12VDC, 290 mA @ 24VDC
• Special Attributes: IEC Ex Zone 1 certified, ATEX Zone 1 certified
• Vessel Size: Over 50M
• Minimum Feed Wire Gauge: 0.5mm² AWG22
• Weight: 1.49 Kg (52.55 Oz)

Lopolight 300-136-PRO-I - Navigation Light 6NM 225° White Masthead Black Anodized

Advanced navigation light with integrated de-icing for consistent operation in extreme conditions. Designed for horizontal mounting on large vessels with reliable IP68 protection.

• Built-in de-icing function for cold climates
• Mounted horizontally on 400-037 POM base (IP68)
• Cable direction: side, includes HDPE base plate
• Compatible with 7-13mm (9/32""-1/2"") cables via quality cable glands
• Model Number: 300-136-PRO-I
• Light Color: White
• Dimensions: Ø92.5mm x 126.8mm (3.6"" x 4.9"")
• Certification: DNV
• Light Intensity: >94cd
• Approved to: COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR
• Visibility Range: 6 NM
• Operating Temperature: -60°C to 55°C
• Mounting: Horizontal
• Materials: Black hard coat anodized aluminum 50µ, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane
• Operating Voltage: 20-32VDC
• EAN: 5704438011465
• IP Rating: IP68
• Power Draw: 13 W
• Connection: Plug connector
• Current Consumption: 0 mA @ 12VDC, 580 mA @ 24VDC
• Vessel Size: Over 50M
• Minimum Feed Wire Gauge: 1.5mm² AWG18
• Weight: 1.32 Kg (46.56 Oz)

Lopolight 300-136-PRO-I-EX - Navigation Light 6NM 225° White Masthead Ex Zone 1&2 Ice-Class

Engineered for demanding maritime conditions, this navigation light ensures visibility and reliability in hazardous environments. Ideal for vessels over 50 meters, it features advanced certifications and ice-class functionality.

• Certified for use in ATEX Zone 1 & 2
• Built-in de-icing function for harsh conditions
• Mounted horizontally on 400-037 EX/MIL aluminum base
• Cable direction side, includes HDPE base plate
• No cable glands or ground strap included
• Number: 300-136-PRO-I-EX
• Light color: White
• Dimensions (metric): Ø92.5mm x 140.8mm
• Dimensions (imperial): Ø3.6" x 5.5"
• Certification: DNV, Dancert (Approved to: Ex mb eb IIB T5 Gb), ExVeritas (PQAN/UKQAN/QAR)
• Intensity: >94cd
• Approved to: COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, BV, RINA, LR, MCA, ATEX 2014/34/EU, IEC 60079-0/7/18, UK Ex
• Visibility: 6nm
• Included in package: 1 Navigation light, Installation guide
• Operating temperature: -25°C to 55°C
• Mounting: Horizontal
• Materials: Black hard coat anodized aluminum 50µ, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane
• Operating voltage: 20-32VDC
• IP rating: IP68
• Power draw: 3W
• Connection: Plug connector
• Current consumption: 0 mA @ 12VDC, 290 mA @ 24VDC
• Special attributes: Ice-class defroster, IEC Ex Zone 1 certified, ATEX Zone 1 certified
• Vessel size: Over 50M
• Minimum feed wire gauge: 0.5mm² (AWG22)
• Weight: 1.49 Kg / 52.55 Oz
• EAN: 5704438040724
• UPC Code: 879343040857
